L-9025 - Motor Characteristics
L-9025 Motor Characteristics
| Part Number | L-9025 | |||
|---|---|---|---|---|
| Gear Reduction Type | - | Direct Drive | ||
| Rated Voltage | V | 24 | ||
| Rated Current | A | 3.36 | ||
| Rated Torque | Nm | 2.79 | ||
| Rated Speed | RPM | 130 | ||
| Max Speed | RPM | 280 | ||
| Peak Torque | Nm | 5.8 | ||
| Peak Current | A | 7.6 | ||
| Phase Resistance | Ohm | 1.9 | ||
| Connection Type | - | Y | ||
| Phase Inductance | mH | 4.71 | ||
| Speed Constant | RPM/V | 12 | ||
| Torque Constant | Nm/A | 0.76 | ||
| Rotor Inertia | gcm² | 4656 | ||
| Number of Pole Pairs | - | 14 | ||
| Motor Weight | g | 880 | ||
| Working Temperature | C | -20 ~ 80 | ||
| Max Demagnetize Temperature | C | 120 | ||
| Control Precision | deg | 0.001 | ||
| Drive | - | MC200 | ||
| Input Voltage | V | 8-36 | ||
| Current | A | Nominal: 8A; Instantaneous: 15A | ||
| Rated Power | W | 200 | ||
| Encoder | - | 14-bit Magnetic Encoder | ||
| Communication Method and Baud Rate | - | CAN BUS :1M ; RS485: 115200/500k/1M/2.5M | ||
| Control Mode | - | Torque loop (current loop) / speed loop / position loop | ||
| S-Curve | - | Yes | ||
